Freedom of Flying
Armattan Badger 5”
In Service: 7/2021
New addition to the stable. This frame will replace the Rooster. Originally wanted to run a Caddx Turtle V2 DVR but coaxial cable was too short. Phoenix 2 is a better image quality though.
— — —
T-Motor F722 Mini
T-Motor F45A+
T-Motor P2306 2550KV
RunCam Phoenix 2 JB Edition
TBS Pro HV VTX
TBS Crossfire Nano RX
GemFan Hurricane 51433
Lumenier AXII 2 Right-Angle Stubby 5.8GHz Antenna (LHCP)
In Service: 4/2021
RTF Model, replaced VTX and RX, custom printed bardpole holder with upgraded to diversity RX
— — —
Goku 16x16 Micro Stack
Goku GM9 Mini GPX v1.0
Flywoo/Dave_c motor 1404 2750KV
Matek MICRO BEC 6-30V TO 5V/9V-ADJ
ImmersionRC Tramp Nano (US version) 1mW>500mW+ U.Fl
TBS Crossfire Diversity Nano RX
TRUERC BARDPOLE 915 MHZ U.FL
GEMFAN Hurricane 4024
Diatone Mamba Ultras 5.8G UFL Antenna - LHCP
FlyWoo Explorer V2
Armattan Gecko 3”
In Service: 2/2021
Originally a RTF model but the CL Racing F4 Mini FC CPU lid ruptured on power up. Replaced the FC and 4in1 ESC with a Mamba stack.
— — —
Mamba F405 Mini MK2
Mamba F30 Mini 30A
Armattan OOmph TITAN Mini - 1407/3650KV
Caddx Turtle V2 DVR
TBS Unify Pro 5G8 HV VTX
TBS Crossfire Nano RX
Gemfan Windancer 3028
ORT Micro Vee Linear 5.8GHz Antenna - U.FL
Armattan Rooster 5”
In Service: 4/2019
One of the oldest Armattan models and the first 5” custom built. She’s an old girl but still flies great.
— — —
Diatone Mamba Power Tower MK2 F405
Diatone Mamba F30 ESC
BrotherHobby Returner R5 2306 2650kv
RunCam Phoenix 2 JB Edition
TBS Pro HV VTX
TBS Crossfire Nano RX
GemFan Hulkie 5055
Lumenier AXII 2 Right-Angle Stubby 5.8GHz Antenna (LHCP)
